Maximum Protection: Premium Chromium Carbide Wear Plates

Engineered for the Toughest Industrial Environments

When your operations involve heavy impact and extreme abrasion, standard steel isn’t enough. Our Chromium Carbide Overlay (CCO) Wear Plates provide a dual-layer defense system designed to outlast AR400 and AR500 steel by up to 10 times.

Why Choose Our CCO Wear Plates?

Our plates feature a mild steel base for weldability and a thick, hardfaced overlay of chromium carbide. This combination ensures your machinery stays in production longer, significantly reducing downtime and maintenance costs.

Key Performance Benefits

  • Superior Hardness: The overlay reaches a typical hardness of 58–62 HRC, providing a formidable barrier against sliding abrasion.
  • Exceptional Microstructure: High volume of primary Cr7C3 carbides (minimum 30%) provides the "backbone" of our wear protection.
  • Impact Resistance: The ductile base plate absorbs energy, preventing the brittle carbide layer from shattering under heavy loads.
  • Heat Tolerance: Maintains structural integrity and wear resistance in temperatures up to 600°C (1100°F).

Technical Specifications

PropertyStandard Specification
Base MaterialQ235B / A36 Mild Steel (Custom options available)
Hardness Range58 - 62 HRC
Carbide ContentCr7C3 (Primary Carbides)
Standard Sizes1400 x 3400mm, 1500 x 3000mm
Thickness Range3+3, 4+4, 6+4, 8+6, 10+10, 12+12 (and custom)

Common Industrial Applications

Our wear plates are the industry standard for protecting high-wear zones in:

  • Mining: Chutes, liners, hopper bins, and shovel buckets.
  • Cement: Separator vanes, discharge pipes, and clinker chutes.
  • Steel/Power: Coal feeder liners, fan blades, and vibrating feeders.
  • Recycling: Conveyor liners and shredder housing.

Custom Fabrication & Services

We don't just sell plates; we provide solutions. Our facility is equipped to deliver:

  1. Precision Cutting: CNC Plasma or Waterjet cutting to your exact CAD drawings.
  2. Forming & Rolling: Custom radii for pipe liners and curved chutes.
  3. Countersunk Holes: For easy bolt-on installation.

Ready to Reduce Your Downtime?

Don’t let abrasion erode your bottom line. Contact our technical sales team today for a quote or a material consultation.
